| Nama merek: | mstar |
| Nomor Model: | MNPS-190-03-NF |
| MOQ: | 1 |
| harga: | 36 |
| Rincian kemasan: | 25*20*10cm Potongan/potongan |
| Ketentuan Pembayaran: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Nomor model. | MNPS - 190 - 02 - NF | ||
|---|---|---|---|
| Frekuensi ((MHz) | 138 - 960 | ||
| Nomor port input | 1 | ||
| Nomor port output | 2 | 3 | 4 |
| Rugi Pembagian ((dB) | 3.0 | 4.8 | 6.0 |
| IL(dB) | 0.6 | 1.0 | 1.0 |
| Isolasi | 20 | 17 | 17 |
| VSWR | ≤ 1.30 | ||
| PIM ((dBc) | ≤ - 153dBc@2*43dBm | ||
| Total Daya Masuk (W) | 50 | ||
| Impedansi | 50 ohm | ||
| Konektor | N - betina | ||
| Warna | Hitam | ||
| Temp ((deg) | -30 - +70 | ||
| Aplikasi | Di dalam atau di luar ruangan, IP65 |
|
|
