| Nama merek: | MSTAR |
| Nomor Model: | LX15-5B |
| MOQ: | 1 |
| harga: | 1326 |
| Rincian kemasan: | 25*20*10cm Potongan/potongan |
| Ketentuan Pembayaran: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Posisi | Hubungan atas | Downlink | ||
| Jangkauan Frekuensi | Band 12 | 704 ~ 716 MHz | 734~746 MHz | |
| Band 13 | 776 ~ 787 MHz | 746 ~ 757 MHz | ||
| Band 5 | 824~849 MHz | 869 ~ 894 MHz | ||
| Band 4 | 1710~1755 MHz | 2110~2155 MHz | ||
| Band 2 | 1850~1910 MHz | 1930 -1990 MHz | ||
| Kekuatan output | 10± 2d8m | 15± 2dBm | ||
| Keuntungan | 60 ± 2dB | 60±2dB | ||
| Ripple | Band 12 | ≤ 8 dB | ≤ 8 dB | |
| Band 13 | ≤ 8 dB | ≤ 8 dB | ||
| Band 5 | ≤ 8 dB | ≤ 8 dB | ||
| Band 4 | ≤ 8 dB | ≤ 8 dB | ||
| Band 2 | ≤ 15 dB | ≤ 15 dB | ||
| Max.Input | Kekuatan Tanpa Kerusakan | -10 dBm | -10 dBm | |
| Emisi Palsu | 9KHz ~ 1GHz | ≤-36 dBm | ≤-36 dBm | |
| 1GHz ~ 12,75GHz | ≤-30 dBm | ≤-30 dBm | ||
| ALC Aktif 20dB | ≤2dB | ≤2dB | ||
| Alarm | ALC tidak aktif | Hijau | ||
| ALC Aktif 5 ~ 10dB | Oranye | |||
| ALC Aktif 15 ~ 20dB | Merah | |||
| Osilasi diri | Merah berkedip | |||
| (uplink OFF) | ||||
| Penundaan Waktu | ≤ 0,5 μs | ≤ 0,5 μs | ||
| Sumber Daya | DC: 5 V | |||
| Konsumsi Daya | < 20W | |||
| Konektor RF | N-Wanita | |||
|
|
